STEP-files for load cells,
weigh modules and instruments



Download ready-to-use 3D CAD models for BLH Nobel products in neutral .STEP format. Import them straight into SolidWorks, Autodesk Inventor, AutoCAD, CATIA, Creo, Fusion 360 or any CAD system to design mounting arrangements, check clearances and fit, run clash detection, and integrate our load cells and modules into your machine or plant layout before anything is built.


Every model below opens directly from our document server. Can't find the model or capacity you need?
Talk to an application engineer and we'll get you the right file.

About blh nobel
Request a CAD Model



Download library

All STEP models by product family

58 CAD models across our load cell, weigh module, web tension and instrument ranges.

KIS

Shear beam load cells & weigh modules22 models
KIS-1 50 kN Load Cell↓ STEP KIS-1 50 kN Module↓ STEP KIS-1 100 kN Load Cell↓ STEP KIS-1 200 kN Load Cell↓ STEP KIS-1 200 kN Module↓ STEP KIS-1 300 kN Module↓ STEP KIS-1 500 kN Load Cell↓ STEP KIS-1 500 kN Module↓ STEP KIS-2 1-5 kN Module↓ STEP KIS-2 5 kN Load Cell↓ STEP KIS-2 10 kN Load Cell↓ STEP KIS-2 10-30 kN Module↓ STEP KIS-2 20 kN Load Cell↓ STEP KIS-8 1-2 kN Module↓ STEP KIS-8 5-20 kN Module↓ STEP KIS-8 30 kN Module↓ STEP KIS-8 50 kN Module↓ STEP KIS-8 100 kN Module↓ STEP KIS-8 200 kN Module↓ STEP KIS-9 5-20 kN Module↓ STEP KIS-9 50 kN Module↓ STEP KIS-9 100 kN Module↓ STEP

KISD

Double-ended shear beam load cells3 models
KISD-6R 50 kN Load Cell↓ STEP KISD-6R 400 kN Load Cell↓ STEP KISD-6R 1000 kN Load Cell↓ STEP

KIMD

Load cells & high-capacity modules3 models
KIMD-1 500-800 kN Load Cell↓ STEP KIMD-1 500-800 kN Module↓ STEP KIMD-M 0,5-1 MN↓ STEP

KOM

Weigh modules4 models
KOM-1 10-50 kN Module↓ STEP KOM-1 100 kN Module↓ STEP KOM-1 200 kN Module↓ STEP KOM-1 500 kN Module↓ STEP

KOSD

Double-ended shear beam load cells8 models
KOSD-5 20-50-100 kN Load Cell↓ STEP KOSD-40 10 kN Load Cell↓ STEP KOSD-40 100 kN Load Cell↓ STEP KOSD-40 200 kN Load Cell↓ STEP KOSD-40 500 kN Load Cell↓ STEP KOSD-101 1 MN Load Cell↓ STEP KOSD-107 1 MN Load Cell↓ STEP KOSD-115 2 MN Load Cell↓ STEP

KDH

High-capacity weigh modules5 models
KDH-1 200 klb Load Cell↓ STEP KDH-1A 200 klb Module↓ STEP KDH-5 20-50-100 kN Module↓ STEP KDH-5 1 MN Module↓ STEP KDH-5 2 MN Module↓ STEP

TankMount

Tank & vessel weigh modules2 models
TankMount 500-2000 kg↓ STEP TankMount 5000 kg↓ STEP

FMU

Web tension measurement units6 models
FMU-1 2-10 kN Module↓ STEP FMU-1 20-60 kN Module↓ STEP FMU-1 100 kN Module↓ STEP FMU-1 200 kN Module↓ STEP FMU-5 100 kN Module↓ STEP FMU-5 400 kN Module↓ STEP

HTK

Web tension module1 model
HTK 0,5-5 kN Module↓ STEP

G-Series instruments

Panel & rail-mount transmitters4 models
G4-PM↓ STEP G4-RM↓ STEP G5-PM↓ STEP G5-RMD↓ STEP
Questions, answered

Working with our CAD models

What is a STEP file?

A STEP file (.STEP or .stp, ISO 10303) is a neutral 3D CAD format that almost every CAD system can open. It carries the full solid geometry of the part, so you can place an accurate model of a BLH Nobel load cell or weigh module directly into your own assembly.

Which CAD software can open these models?

Any major CAD package — including SolidWorks, Autodesk Inventor, AutoCAD, CATIA, Creo, Siemens NX and Fusion 360 — can import STEP files, regardless of which system the model was created in.

What can I use the models for?

Use them to design mounting and foundation details, verify clearances and envelope dimensions, check for interference (clash detection), and integrate the product into a machine, skid or plant layout before manufacturing — reducing rework and commissioning surprises.

You don't list a model for the product I need — can I still get one?

Yes. The library covers our most-requested load cells, weigh modules, web tension units and instruments. If the exact product or capacity you need isn't here, contact our application engineers and we'll provide the CAD model.

Need a model that isn't listed?

Tell us the product and capacity you're designing around, and our application engineers will get you the right CAD model and specify the best fit for your application.
